⚡ Quick Answer

Kubota requires an ethylene glycol-based, phosphate-free, silicate-free coolant meeting Super Coolant LLC (SLLC) specifications. Genuine Kubota part 70040-0L014 (concentrate) or 77700-06325 (50/50 premix). Approved aftermarket alternatives: Zerex G-05, Prestone Asian Vehicle, Peak Asian — all HOAT Asian formula matching Kubota specs exactly. Use 50/50 mix for most climates (-34°F protection). Change every 2 years or 2,000 hours. Never use universal green, Dex-Cool, or European blue coolant in any Kubota engine.

💡 What Color is Kubota Coolant?

Genuine Kubota Super Coolant is blue-green in color. Approved aftermarket alternatives like Zerex G-05 are also blue-green. If your coolant looks bright green — that’s universal green coolant which is NOT compatible with Kubota engines. Orange or red coolant (OAT/Dex-Cool) is also incompatible. When in doubt, drain and refill with the correct HOAT Asian formula — mixing incompatible types causes gelling and clogs.

Kubota Coolant Specs by Model Series

Series	Models	Coolant Type	Capacity	Color
BX Series	BX1880, BX2380, BX2680, BX23S	SLLC / Asian HOAT	1.8–2.3 qts	Blue-green
B Series	B2301, B2401, B2601, B2650	SLLC / Asian HOAT	2.5–4.0 qts	Blue-green
L Series	L2501, L3301, L3901, L4701	SLLC / Asian HOAT	6.1–14.8 qts	Blue-green
M Series	M5, M6, M7 (inc. M7060)	SLLC / Asian HOAT	8–14 qts	Blue-green

All Kubota models use the same Asian HOAT formula — only capacity differs. See our complete fluid capacity chart for exact model-specific volumes.

1. What Coolant Does Kubota Require?

Kubota specifies an ethylene glycol-based coolant free of silicates, nitrites, borates, and amines — meeting Super Coolant LLC (SLLC) standards. This HOAT (Hybrid Organic Acid Technology) formula provides superior wet-sleeve liner protection against cavitation erosion, which is a common diesel failure mode that universal green coolant does not prevent.

⚠️ What NOT to Use:

Universal green coolant — silicate-heavy, attacks aluminum components and clogs narrow radiator passages
Dex-Cool / OAT formula — orange/red color, lacks wet-sleeve liner protection, not Kubota-approved
European blue coolant — wrong inhibitor package for Japanese diesel engines
Tap water — mineral buildup causes scale and reduces cooling efficiency

✅ OEM — Kubota Super Coolant

Concentrate: 70040-0L014
Premix 50/50: 77700-06325
Cost: $28–32/gal
Life: 2 years / 2,000 hrs

✅ Approved Aftermarket

Zerex G-05 — phosphate HOAT
Prestone Asian Vehicle
Peak Asian Green
Cost: $15–20/gal — saves 40%

❌ Do NOT Use

Universal green (silicate)
Dex-Cool / OAT (orange)
European blue
Any “universal” formula

🛢️ Approved Kubota Coolant — Aftermarket Options Save 40%:

All three match Kubota Super Coolant SLLC specs exactly — phosphate HOAT, no silicates, no nitrites. Always mix 50/50 with distilled water or use premix.

Zerex G-05 Antifreeze/Coolant — Phosphate HOAT, No Silicate

Direct OEM-equivalent — most widely used aftermarket alternative for BX and L series owners (~$18/gal)

View

Prestone Asian Vehicle Antifreeze 50/50 Premix — Ready to Use

No mixing required — pour directly into system. Phosphate-based HOAT, silicate-free, fits all BX, B, L and M series (~$20/gal)

View

Peak Asian Premix Antifreeze — Budget-Friendly OEM-Spec Option

Asian HOAT formula — same spec as Zerex G-05 at competitive pricing, confirmed compatible with all Kubota models

View

Refractometer — Test Coolant Mix Ratio & Freeze Protection

Test for 32–36% glycol concentration after any coolant change or top-off — essential for accurate freeze point verification (~$25)

View

As an Amazon Associate, TractorPartsCentral earns from qualifying purchases.

2. Coolant Mix Ratios by Climate

Climate / Region	Mix Ratio	Freeze Protection	Notes
Most U.S. regions	50/50	-34°F / -37°C	Standard — use premix or mix with distilled water
Northern states (MN, ND, MT)	60/40	-52°F / -47°C	Polar vortex protection — do not exceed 70%
Southern states (TX, FL, AZ)	40/60	-12°F / -24°C	More water improves heat transfer by 5%
Extreme cold storage	70/30 max	-62°F / -52°C	Never exceed 70% — gelling risk above this

Always use distilled water — tap water contains minerals that cause scale buildup. Use our Kubota Coolant Mix Calculator for exact ratios by model.

3. Coolant Capacity by Model

Model	Total Capacity	Radiator Only	Premix Needed (50/50)
BX2380 / BX23S	2.3 qts	1.2 qts	~1 qt premix
BX2680 / BX1880	1.8–2.1 qts	1.0–1.2 qts	~1 qt premix
B2601 / B2650	3.5–4.0 qts	2.2–2.5 qts	~1 gal premix
L2501 / L3301	6.1 qts	3.5 qts	~1.5 gal premix
L3901 / L4701	6.3–14.8 qts	4.0–8.5 qts	~2–4 gal premix
M7060	11.4 qts	6.8 qts	~3 gal premix

Never fill cold system to the top — underfill by 0.5 qt, run engine 10 minutes, then top off from reservoir. Thermal expansion overflows at operating temperature.

4. DIY Coolant Change Procedure

💡 Tools needed: 5-gallon drain pan — long-neck funnel — refractometer — distilled water — nitrile gloves — shop towels. Time: 45 minutes. DIY saves $250 vs dealer service.

Let engine cool completely — minimum 2 hours after shutdown. Never open a hot radiator cap — pressurized coolant causes severe burns.

Open radiator petcock and drain — attach a hose to direct into drain pan. Allow 10–15 minutes for full drain. M series requires block drain removal for complete flush.

Close petcock, fill with 50/50 premix — use long-neck funnel to prevent air pockets. Fill slowly until coolant rises to radiator neck. Do not overfill — leave 0.5 qt of space.

Start engine, idle at 1,500 RPM — run with heater on max for 15 minutes. Top off every 2 minutes as air burps out of the system. Rock tractor front-to-back if air pockets persist.

Shut off, cool 30 minutes, check level — verify cold fill mark at reservoir. Top off as needed. Check radiator cap seal — replace if cracked or soft.

Test with refractometer — sample from reservoir should read 32–36% glycol for standard 50/50. Also verify pH 7.5–8.5 with test strips. Document date and hours for next service interval.

5. Coolant Service Schedule

Interval	Task	Why It Matters
Every fill-up	Check reservoir level	Catch leaks before overheating occurs
Every 200 hrs	Visual inspection — color, clarity	Milky = contamination, rusty = corrosion
Annually	Test freeze point with refractometer, check pH	Inhibitors deplete over time even if level looks fine
Every 2 yrs / 2,000 hrs	Full drain and refill	Extended-life formula reaches end of inhibitor life
Before storage	Verify freeze protection for your climate	Freeze cracks cost $1,800+ to repair

Kubota coolant service is straightforward — the right formula is any Asian HOAT coolant (Zerex G-05, Prestone Asian, Peak Asian) mixed 50/50 with distilled water. Change every 2 years or 2,000 hours, verify with a refractometer, and never use universal green or Dex-Cool. A $45 DIY coolant change prevents $1,500–3,800 in water pump and head gasket repairs. For more Kubota maintenance guides visit TractorPartsCentral.com.

? Frequently Asked Questions

What color is Kubota antifreeze?

Genuine Kubota Super Coolant is blue-green in color. Approved aftermarket alternatives like Zerex G-05 and Prestone Asian Vehicle are also blue-green. If your coolant is bright green it’s universal green coolant which is not compatible. Orange or red coolant is Dex-Cool/OAT which is also incompatible. When in doubt about what’s in your system, drain and refill with the correct HOAT Asian formula rather than mixing unknown coolant types.

How often should I change Kubota antifreeze?

Kubota extended-life coolant lasts 2 years or 2,000 hours whichever comes first. Test annually with a refractometer — if glycol concentration drops below 32% or pH drops below 7.5 the inhibitors are depleted and it’s time to change. Flush immediately if coolant appears milky (water contamination) or rusty (corrosion). DIY cost is $45 for a full drain and refill vs $295 dealer service.

Can I use Prestone or Zerex in a Kubota tractor?

Yes — Prestone Asian Vehicle and Zerex G-05 both match Kubota Super Coolant SLLC specifications exactly. Both are phosphate HOAT formula with no silicates or nitrites. They cost $15–20/gallon vs $28–32 for OEM — a 40% saving. Always verify the label says “Asian Vehicle” or “HOAT Asian” and confirms no silicates. Standard Prestone green is NOT compatible — it contains silicates that attack aluminum components.

What is the Kubota antifreeze equivalent at AutoZone or NAPA?

Zerex G-05 is the most widely available OEM-equivalent at AutoZone, NAPA, and O’Reilly. Prestone Asian Vehicle and Peak Asian Green are also stocked at most auto parts stores. All three match Kubota Super Coolant specs — look for “Asian Vehicle” or “HOAT” on the label and confirm no silicates. Avoid anything labeled “universal” or “all makes all models” as these typically contain silicates.

What is the difference between concentrate and premix antifreeze?

Concentrate (Kubota 70040-0L014) requires mixing 50/50 with distilled water — one gallon of concentrate makes two gallons of coolant. Premix (77700-06325) is ready to pour directly into the system. Concentrate saves money on large fills (M7060’s 11.4 qt system) but requires accurate measuring. Premix eliminates mixing errors and is the safer DIY choice for smaller BX and B series fills. Both provide identical -34°F freeze and 325°F boil protection at 50/50.

Can I mix different brands of Kubota-compatible coolant?

Yes — mixing any two HOAT Asian coolants (Zerex G-05, Prestone Asian, Peak Asian, OEM Kubota) is safe as long as both meet Super Coolant LLC specs. Never mix with universal green, Dex-Cool, or European blue — incompatible inhibitor packages cause gelling and precipitation that clogs narrow radiator passages. If unsure what’s currently in the system, do a full drain and refill rather than topping off with a different brand.

How do I dispose of old Kubota coolant?

Collect drained coolant in sealed containers — never pour down drains or on the ground. Ethylene glycol is toxic to animals. AutoZone, NAPA, and O’Reilly accept used coolant for free recycling. County hazardous waste sites also accept it. Label containers “Used Antifreeze — Toxic” and store away from pets. Most states have $500+ fines for improper disposal.
